How to add CAD bodies in Fusion 360!

How to add CAD bodies in Fusion 360!

Sometimes I need to add CAD bodies to other CAD bodies in Fusion 360.

First I make sure both are uploaded into Fusion. Next I simply drag the 2nd CAD from the data panel into the design workspace. I can then use the rotation or translation options to make sure the additional CAD body is in the correct location.

How do you add CAD bodies in Fusion 360?
