How to use the Section Analysis in Fusion 360!

How to use the Section Analysis in Fusion 360!

Anytime I get a CAD model or mold assembly, I bring it into Fusion first.

For mold assemblies, one of the first tools I use is the Section Analysis (Design workspace – Solid tab – Inspect – Section Analysis).

I select a flat surface on the mold and click and drag through the thickness of the entire mold. This allows me to understand the tool construction (2-plate vs 3-plate), runner type (cold runner vs hot runner), cooling layout, inserts, and the number of cavities.

Once I understand the mold, I can turn off the Section Analysis in the model tree and start to prepare the model for Moldflow.

Have you ever used the Section Analysis in Fusion 360?

For more news about Moldflow and Fusion 360, follow MFS and Mason Myers on LinkedIn.
